Máy Thổi Khí Ly Tâm - Treo Khí

NGÀNH NƯỚC

Nhà máy xử lý nước thải / nước thải

Máy thổi khí liên quan đến xử lý sinh học nước thải trong các nhà máy xử lý nước thải đô thị, nhà máy, khu công nghiệp.

Kiểm soát hạ lưu

Bioactive Response System (BARS) là một hệ thống điều khiển hoàn toàn tự động, hiệu quả cao, giúp tối ưu hóa hoạt động của quạt sục khí tăng áp

KHAI THÁC MỎ

Sản xuất Irom

Máy thổi khí ứng dụng cho các lò phản ứng (thổi nóng) và khí đốt

Luyện kiem loại

Máy sục khí, oxy hóa và thổi khí đốt cho các quá trình sinh học và chuyển hóa

Máy thổi khí oxy hóa cho quá trình luyện kim

CÔNG NGHIỆP

Carbon Black

Blowers providing combustion air for the associated furnaces

Effluent Treatment

Aeration blowers associated with the biological treatment of effluent within industrial plants

Fermentation

Air blowers associated with biochemical fermentation within pharmaceutical and yeast production markets

Mechanical Vapor Recompression

Air blowers used to recompress vapor generated during an evaporation process so that it can be used as the heating medium for the same evaporation process

 NĂNG LƯỢNG

Circulating Fluidized Bed Combustion

Blowers providing fluidizing air within the loop seal system on a circulating fluidized bed

Flue Gas Desulphurization

Oxidation air blowers associated with the cleaning of flue gases produced within power and heavy industrial plants

      HÓA DẦU / TINH CHẾ

Fertilizer Production

Blowers / Compressors providing atomizing air for fertilized bed

Sulphur Recovery Units

Blowers/compressors providing reaction air for the catalytic recovery of Sulphur within refineries and gas processing facilities

57%
ENERGY
REDUCTION

Low Vibration Under 1.0 mm/s

Low Noise Under 80dB ± 3dB

Only air filter changes required

1

MOTOR COOLING SYSTEM

PATENT # : 10-1580877 / 10-1607492

TyphoonCompressor's motor cooling system has a patented two-stage cooling structure that can lower the motor temperature more than 10 degrees compared to other brands. The air cools stator, bearing, winding and rotor. The heated air is exhaused outside of the enclosure.

2

HIGH EFFICIENT

PERMANENT MAGNET MOTOR

TyphoonCompressor PM motor is a high efficient (95%), self-designed and manufactured product, which can perform at ultra-high speed ranging from 20,000 to 150,000 RPM.

3

HIGH PERFORMANCE IMPELLER

TyphoonCompressor’s impeller is an in-house designed and manufactured product. It guarantees high-efficiency with same quality all the times. It is made of high strength aluminum alloy (AL7075-T651) that is precisely processed up to 0.001mm thickness.

Our impeller with. hard anodizing on the surface has an excellent corrosion and chemical resistance, so it has an excellent performance in hostile environments. Turbowin also provide stainless steel and titanium impellers.

4

AIR FOIL BEARING

PATENT # : 10-1632356 / 30-0858674

The frictionless characteristic of our oil-less air foil bearing makes it extremely durable. Our bearing has passed On/Off testing of over 100,000 cycles.

5

ON-MACHINE REAL TIME PARAMETER MEASUREMENT

PATENT # : C-2016-006451

The control system, which measures pressure, temperature, and flow rate in real time, controls the VFD and BOV quickly and precisely. Our bell-mouth flow meter can measure the flow within ± 0.5% tolerance (JIS B 8340).

1. Water resistant enclosure PATENT # : 10-1616274

Patented water resistant enclosure for outdoor applications, a simple overhead canopy and covers on inlet louvers are often all that is required.

2. BOV(Blow Off Valve) PATENT # : 10-1651589

The BOV protects the core from surge during operation and in emergency circumstances. Our patented BOV has a unique design that is operated by internally generated differential pressure without supply of external compressed air.

3. Rotor Locking Device PATENT # : 10-1791977

All TyphoonCompressor machines are shipped with our patented rotor locking device. This is to minimize any damage during transportation and installation period.

4. Control Panel

The Control Panel can utilize either a PLC or MICOM controller, based on the customers preference. For the PLC option, we can offer any of Allen-Bradley, SIEMENS, RS-AUTO or LG. The control panel can be connected remotely to plant SCADA via Ethernet, RS485 or RS422.

5. User Interface Panel

All Typhoon Compressor control systems use either a 7 or 10 inch touch screen so that users can easily and precisely control operational targeting values and control parameters . Four operation switches (RUN, LOAD, STOP, EMERGENCY) allow proper operation during normal and emergency conditions.

6. VFD Cooling System

Typhoon Compressor blowers use UL/CE certified VFD from well known industry suppliers to run the high-speed motor. VFD Cooling Air can be either passed from the electrical compartment into the core compartment (Type A), or it can be ducted to the outside of the enclosure (Type B). The image to the right depicts the Type A cooling system.

7. Suction / Process Air Filtering System

Intake air passes through a non-woven free-filter and a pleated main air filter (combined minimum efficiency 85%) to effectively remove potentially harmful contaminants. The filter can be replaced easily even during operation.
