Water-lubricated Oil-free
Single Screw Air Compressor
|
Dry Oil-free
Double Screw Air Compressor
|
| Working Principle |
Water-lubricated Oil-free Single Screw
|
Dry Oil-free Double Screw
|
| Air Quality |
100% Oil Free |
Oil in the gear |
| Air Purity |
Clear air after purified by water |
Contain dust and oil stain |
| Lubrication Media |
Pure Water |
Dry |
| Air Temp |
Less than 55℃ |
About 180~200℃ |
| Compression |
Single-Stage |
Two-stage |
| Cooling method |
Don’t need cooling system |
Need interstage and after Cooling system |
| Structure |
Simple and Balance Structure |
Radial load is not balance |
| Vibration and Noise |
Low vibration and noise |
High frequency noise due to the two screws |
| Durability |
Ideal Rotation speed 3000r/min, theoretically zero load.
Long lifetime of the screw (30000h) and star wheel (50000h)
|
Rotation speed 18000r/min, high loads on screws.
Short lifetime of screw (8000~18000h)
|
| Maintenance |
Only air and water filter elements |
More spare parts |
7~10bar Water-lubricated Oil-free Screw Air Compressor (VSD/PM VSD)
| Model |
Pressure |
Capacity |
Power |
Noise |
Dimension
(mm)
|
Weight |
| OTVS08F |
7 bar
8.5bar
10bar
|
1.3m³/min
1.1m³/min
0.9m³/min
|
7.5 kW
10 HP
|
57dB |
1100×750×1320 |
430kg |
| OTVS11F |
7 bar
8.5bar
10bar
|
1.7m³/min
1.5m³/min
1.3m³/min
|
11 kW
15 HP
|
57dB |
1100×750×1320 |
450kg |
| OTVS15F |
7 bar
8.5bar
10bar
|
2.5m³/min
2.2m³/min
2.0m³/min
|
15 kW
20 HP
|
57dB |
1590×870×1500 |
570kg |
| OTVS18F |
7 bar
8.5bar
10bar
|
3.2m³/min
2.8m³/min
2.5m³/min
|
18.5kW
25 HP
|
58dB |
1590×870×1500 |
620kg |
| OTVS22F |
7 bar
8.5bar
10bar
|
3.7m³/min
3.4m³/min
3.0m³/min
|
22 kW
30 HP
|
60dB |
1590×870×1500 |
640kg |
| OTVS30F |
7 bar
8.5bar
10bar
|
5.3m³/min
4.7m³/min
4.3m³/min
|
30 kW
40 HP
|
61dB |
1690×1000×1600 |
980kg |
| OTVS37F |
7 bar
8.5bar
10bar
|
6.2m³/min
5.6m³/min
5.0m³/min
|
37 kW
45 HP
|
61dB |
1690×1000×1600 |
1010kg |
| OTVS45F |
7 bar
8.5bar
10bar
|
7.6m³/min
6.8m³/min
6.0m³/min
|
45 kW
60 HP
|
65dB |
2350×1250×1750 |
1110kg |
| OTVS55F |
7 bar
8.5bar
10bar
|
10.0m³/min
9.0m³/min
7.8m³/min
|
55 kW
75 HP
|
67dB |
2350×1250×1750 |
1200kg |
| OTVS75F |
7 bar
8.5bar
10bar
|
13.0m³/min
12.0m³/min
10.0m³/min
|
75 kW
100HP
|
71dB |
2800×1450×1900 |
1550kg |
| OTVS90S |
7 bar
8.5bar
10bar
|
16.8m³/min
15.0m³/min
14.0m³/min
|
90 kW
120HP
|
72dB |
2450×1450×1700 |
2250kg |
| OTVS110S |
7 bar
8.5bar
10bar
|
20.0m³/min
18.5m³/min
16.0m³/min
|
110kW
150HP
|
74dB |
2450×1450×1700 |
2450kg |
| OTVS132S |
7 bar
8.5bar
10bar
|
25.0m³/min
23.0m³/min
20.0m³/min
|
132kW
180HP
|
77dB |
2450×1450×1700 |
2450kg |
| OTVS160S |
7 bar
8.5bar
10bar
|
27.0m³/min
25.5m³/min
24.0m³/min
|
160kW
215HP
|
78dB |
2800×1500×1900 |
2600kg |
| OTVS1855S |
7 bar
8.5bar
10bar
|
33.8m³/min
31.0m³/min
28.8m³/min
|
185kW
250HP
|
78dB |
2800×1500×1900 |
3000kg |
| OTVS250S |
7 bar
8.5bar
10bar
|
43.0m³/min
41.0m³/min
38.8m³/min
|
250kW
340HP
|
79dB |
3100×2250×2200 |
4500kg |
Details
Air end
Since 1988
Material: Stainless steel, copper alloy, polymers
Motor
Direct Drive
Insulation Class: F Protection Level: IP55 Bearing: SKF
Separator
Clean and Safe air
Material: Medical Stainless steel
Cooler
High Efficiency
Material: Copper Best Quality and Structure
Inverter & Electric
Inverter/PLC: Inovance
Thermal relay/ A.C. Contractor: Siemens
Control Pannel
Brand: Inovance
Display all operation parameters and alarm system
Water Softener
Brand: Pentair
Offer pure lubricating water and extend the service life of air end
Control Valve
Brand: SMC
Imported famous brand component to ensure the stability
Advantages
100% OIL-FREE
– More than 20 years experiences in Water-lubricated Oil-free technology
– Germany Rhineland TUV Class 0 Oil-free Certification
MOST RELIABLE
– More than 30 years experiences in Single Screw Technology
– Most balance and reliable structure
– Low temperature(< 55℃) reduces the stress on components
LOWEST MAINTENANCE
– Use Water as lubricating medium instead of oil
– Without Oil Air Separation Unit
– Consumable parts are only air and water filter elements
ENERGY SAVING >30%
– Ideal Speed (3000r/min)
– Ideal isothermal compression and no heat waste (<55℃)
– Most Advanced VSD and Two-stage compression technology
LOWEST NOISE
– Super dynamic balanced system and low vibration
– The motor and screw are directly connected without any gear
– Sound absorbing materials are also used in the shell
